Inspection solutions Vistus® Freefall

Your first choice for quality management: Vistus and True In-Process Validation

Request this product Download Datasheet

Product picture of a vistus freefall x-ray inspection system

Product features Freefall metal detection system Vistus

The freefall metal detection system Vistus ensures the reliable inspection and removal of metallic foreign bodies from any kind of food products in powder or granule form that is transported with the use of gravity through a pipe, e.g. milk powder, wheat, nuts or cornflakes.

  • Minimum installation height for easy integration into any application
  • True In-Process Validation. This functionality guarantees correct performance testing
  • Cost effective control of up to four search coils via one terminal

Perfect your metal detection system; choose the right components to suit your needs for your remote terminal using the modular principle for customisation with search coil, pipe, separator and, optionally, True In-Process Validation.

All components of the entire system can be used in zone 22 potentially explosive environments as per the provisions of Directive 94/9/EC.

Applications

  • Fill quantity control
  • Filling and Dosing
  • Weighing

Certifications

  • ATEX

Vistus metal detection technology

  • Maximum detection sensitivity
  • Multi-frequency technology
  • Reliable detection

True In-Process Validation

  • Correct performance validation
  • In the centre of the product flow
  • Validate Ddring operation

Individual configuration

  • Quality pipes certified to food standards
  • Efficient separation systems
  • Minimal installation height

Product details

Protection RatingIP65 (IP69K optional)
Explosion ProtectionApproved for II 1/3D c T120" -5°C  <- Ta <-+40°C
User Interface145 mm (5.7") touchscreen
Relay Outputs

Total of 4 relays - relays 1, 3 and 4 freely programmable

Relative air humidityOperation:< 58% at +55°C  / Storage:< 30% at +70°C, 0% to 90% condensation-free
Ambient TemperatureOperation: -10°C to +55°C
Product Temperature-30 to +55°C, up to +150°C with air cooling
Data interfacesTCP l IP-, RS232-, RS422-, CAN bus, field bus and Profibus
Network ConnectionEthernet
